FHXT Radiographic Bucky Table
The FHXT Model is a cost-effective radiographic table designed for quick and simple routine X-ray examinations. Engineered for general radiography needs, it combines compact design, reliability, and user-friendly features to ensure smooth workflow in clinics, diagnostic centres, and hospitals.
Key Features :
- Quick Installation: Simple design for fast setup.
- Easy Patient Access: Comfortable table height for all patients.
- Accurate Positioning: Tabletop with centre line marking for precise alignment.
- Effortless Movement: Smooth Bucky travel across the entire table length with secure mechanical lock.
- Durable & Strong: Sleek steel fabrication supports heavy patient loads.
- Added Stability: Aluminium table railings with provision for compression band.
Applications :
- General Radiography
- Routine Diagnostic Imaging
- Clinics & Nursing Homes
- Small to Mid-sized Hospitals
Technical Specification :
| Model | FHXT |
|---|---|
| Table Top | |
| Material | White Sumnica 6mm Thk 324/CG Compact |
| Table top to Film distance | 85 mm |
| Table top dimensions | 1830 L x 600 W |
| Table Top Radiolucent Area | 1750 x 540 (mm) |
| Maximum Load | 150 Kg |
| Bucky Device Unit | |
| Reciprocating | Motor & Lever mechanism |
| Max. Cassette Accommodation | Max 43 cm (17”) x 43 cm (17”) |
| Electrical requirement | Single Phase 230V +/- 10%. 50/60 Hz |
| Grid (Standard) | 17 1/4 x 18 7/8 60 Lines 6:1 Ratio |
| Horizontal Bucky Travel | 1050 mm |
| Locks | Mechanical (Electromagnetic optional) |
| Dimension | |
| Size | 1830 L x 650 W x 655 H (mm) |
| Weight | |
| Weight | Approx 45 Kg. |
